Bias/Cita Power
http://citapower.com/led-drivers-new/
Auxiliary Output is 12V
- Universal Input (100-308 VAC, 50/60Hz)
- 0-10V dimming w/no flicker (compatible with IEC60929:2006 – controllable ballasts)
- Constant current output
- Fully potted compact design meets UL IP67, highly reliable in wet locations
- Meets UL/CSA and EN Product Safety requirements (UL 8750 Class 2)
- 3,000 Vac Isolation
- Low standby (Off) power
- Smooth power output promotes longer LED life
- Excellent protection features with auto recovery for all conditions
The PDF Links have additional information and specs.
| Model # | Watts | AC Input Voltage | LED Voltage | Aux mA | PDF Link |
|---|---|---|---|---|---|
| CPWLD14-18U-070A | 14 | 100 - 305 | 15 - 22 VDC @ 700mA | 100 | http://citapower.com/wp-content/uploads/CPWLD14W_V2.1.pdf |
| CPWLD14-36U-035B | 14 | 100 - 305 | 12 - 42 VDC @ 350mA | 200 | http://citapower.com/wp-content/uploads/CPWLD14W_V2.1.pdf |
| CPWLD 4-xxU-yyyA/B | 14 | 100 - 305 | Up to 1050mA (customized to your needs) | 200 | http://citapower.com/wp-content/uploads/CPWLD14W_V2.1.pdf |
| CPWLD35-52U-070A | 35 | 100 - 305 | 18 - 56 VDC @ 700mA | 100 | http://citapower.com/wp-content/uploads/CPWLD35W-V3.1.pdf |
| CPWLD35-56U-035B | 35 | 100 - 305 | 18 - 60 VDC @ 350mA | 200 | http://citapower.com/wp-content/uploads/CPWLD35W-V3.1.pdf |
| CPWLD35-xxU-yyyA/B | 35 | 100 - 305 | Up to 1050mA (customized to your needs) | 200 | http://citapower.com/wp-content/uploads/CPWLD35W-V3.1.pdf |
Citapower AC to DC LED Drivers information (from the citapower.com website.)
